Progan Lift
1 / 5
Hydraulic vertical mobile aluminium alloy lift platform is primarily constructed from high-strength aluminum alloy, offering a compact and elegant appearance. The machine's overall dimensions are minimized and lightweight, ensuring easy and convenient operation.
Designed for versatility, this aluminum-alloy lift can navigate narrow spaces, including standard doors, corridors, and elevators. It serves as an essential assistant for aerial tasks in hotels, supermarkets, airports, museums, and gymnasiums for maintenance and cleaning purposes.
| Model | Platform Height (m) | Working Height (m) | Capacity (kg) | Platform Size (m) | Voltage (V) | Power (kW) | Weight (kg) | Dimensions (m) |
|---|---|---|---|---|---|---|---|---|
| GTWY4-100 | 4 | 5.7 | 125-150 | 0.64*0.58 | AC220V | 0.75 | 200 | 1.18*0.75*1.65 |
| GTWY5-100 | 5 | 6.7 | 125-150 | 0.64*0.58 | AC220V | 0.75 | 250 | 1.3*0.80*1.65 |
| GTWY6-100 | 6 | 7.7 | 125-150 | 0.64*0.58 | AC220V | 0.75 | 280 | 1.3*0.80*1.65 |
| GTWY8-100 | 8 | 9.7 | 125-150 | 0.64*0.58 | AC220V | 0.75 | 300 | 1.28*0.80*1.98 |
| GTWY9-100 | 9 | 10.7 | 125 | 0.64*0.58 | AC220V | 0.75 | 320 | 1.35*0.85*1.98 |
| GTWY10-100 | 10 | 11.7 | 125 | 0.64*0.58 | AC220V | 1.1 | 380 | 1.55*0.9*1.98 |
