Leading Rotary Parking System Security
The Rotary Parking System uses a combination of mechanical and hydraulic technology to rotate vehicles and stack them vertically, maximizing the use of available parking space. The system typically consists of a circular platform that can rotate horizontally, as well as vertical columns with multiple levels of parking spaces. Vehicles are driven onto the platform and positioned in a designated spot. When the system is activated, the platform rotates to align the vehicle with an empty parking space on a different level. Hydraulic lifts are used to raise and lower the vehicles as they are moved vertically within the system. This technology allows for efficient and compact parking solutions in areas where space is limited.
| Model No. | RQB-8 | RQB-10 | RQB-12 | RQB-16 | RQB-20 |
|---|---|---|---|---|---|
| Car Spaces (pcs) | 8 | 10 | 12 | 16 | 20 |
| Motor Power (kw) | 7.5 | 7.5 | 9.2 | 15 | 24 |
| Max Retrieve Time (s) | 100 | 120 | 140 | 160 | 140 |
| Rated Capacity (kg) | 2000 | 2000 | 2000 | 2000 | 2000 |
| Car Size (mm) | LxWxH 5300x2000x1550 | ||||
| Operation | Button, IC Card | ||||
| Model No. | RQB-8W | RQB-10W | RQB-12W | RQB-16W |
|---|---|---|---|---|
| Car Spaces (pcs) | 8 | 10 | 12 | 16 |
| Motor Power (kw) | 9.2 | 9.2 | 15 | 24 |
| Max Retrieve Time (s) | 130 | 150 | 160 | 145 |
| Rated Capacity (kg) | 2300 | 2300 | 2300 | 2300 |
| Car Size (mm) | LxWxH 5300x2100x2000 | |||
| Operation | Button, IC Card | |||
